About Our Hydraulic Power Units

Frames hydraulic systems provide tailor-made solutions for controlling processes at any oil and gas plant, and ensure reliable and safe production conditions.

Why to select Frames/Added values/Advantages/Benefits – Hydraulic Systems

Advantages

Compact design
System integrated total solution
Fully tested prior to delivery
Interface engineering

Applications

Cargo & ballasting tanks FPSO
Direct Hydraulic Control Systems for sub-sea controls, IWOCS, topside & turret actuated valves, cargo handling systems, turret disconnect systems
Safety systems on a production platforms

Products

Wellhead Control Panel
Topside Hydraulic Power Unit
Subsea Hydraulic Power Unit up to 20,000 psi
Topside Umbilical Termination Unit (TUTU)
Cargo Ballasting System (?)

Applications

Cargo & ballasting tanks FPSO
Direct Hydraulic Control Systems for sub-sea controls, IWOCS, topside & turret actuated valves, cargo handling systems, turret disconnect systems
Safety systems on a production platforms

Products

Wellhead Control Panel
Topside Hydraulic Power Unit
Subsea Hydraulic Power Unit up to 20,000 psi
Topside Umbilical Termination Unit (TUTU)
Cargo Ballasting System (?)
Work method, technology and human resources

A strong experience in engineering

Our mission is to provide our customers with value through the provisioning of engineering services, procurement, construction, operation and management of infrastructure and power projects. We consider the empowerment of our human resources to be fundamental in building a permanent knowledge base.

Our mission is to provide our customers with value through the provisioning of engineering services, procurement, construction, operation and management of infrastructure and power projects. We consider the empowerment of our human resources to be fundamental in building a permanent knowledge base.

Applications

Wellhead Control Panel
Topside Hydraulic Power Unit
Subsea Hydraulic Power Unit up to 20,000 psi

Advantages

Compact design
System integrated total solution
Fully tested prior to delivery
Interface engineering

About our Hydraulic Power Units

Frames hydraulic systems provide tailor-made solutions for controlling processes at any oil and gas plant, and ensure reliable and safe production conditions.
A typical Frames HPU is equipped with reservoirs, pumps, motors, filters, accumulators, valves, and instrumentation. All components are controlled by a control system supplied by Frames, or by the client’s own control system.
The hydraulic pressures which can be generated with our HPUs range from 100 up to 1380 bar, achievable by using electrical, pneumatic or booster pumps. The types of hydraulic fluid are also very diverse, ranging from standard mineral oil to water/glycol types of subsea fluid, or biodegradable synthetic oil.
The materials used in Frames HPUs match your unique process conditions, site-specific requirements and third-party requirements, and can therefore include the full range of exotic materials.

About out Wellhead Control Panels

Frames’ wellhead control panels (WHCPs) are vital elements in the main control and safety systems for both onshore and offshore production facilities. Our tailor-made panels enable safe operation of the actuated safety valves in the oil and gas production Xmas trees and flowlines by providing clean, hydraulic power and reliable operating and control features.
Frames has a solid track record of designing and manufacturing various types of single and multi wellhead control panels for monitoring and safety control of oil and gas production wells.
Typical Frames’ WHCPs are designed to meet your unique process conditions and site-specific requirements. All our systems ensure controlled opening and closing of the Xmas tree valves in the event of an emergency shutdown or a process shutdown. This is the reason why all our systems include either hydraulic, pneumatic or electrical control logic, and can be executed as PLC-based stand-alone units or complete with remote

About our Intervention Workover Control Systems (IWOCS)

Frames Intervention Workover Control Systems provide the hydraulic power, monitoring and control facilities to enable installation and intervention of subsea Xmas tree systems without impacting other wells.
A Workover Control System comprises a control room section within a positive pressure-certified container, as well as an HPU section suitable for use in hazardous areas.
Hydraulic power for the subsea operations is generated by the HPU section, and is delivered together with electrical power and signals through umbilicals connected to the subsea equipment.
The Master Control Station provides overall control and monitoring of the subsea systems. The Control Station interfaces with the HPU to monitor its status during installation and work-over activities.

Frames units are designed to comply with international standards such as :

ISO 13628-Design and operation of subsea production systems
IEC61508 and IEC61511-Safety systems
DNV 2.7.1 or 2.7.3 - Design standard for offshore containers
